As the core power source of hydraulic systems, the performance stability of hydraulic pumps directly impacts equipment operational efficiency. As hydraulic technology experts, Guangdong Haozheng Hydraulic Equipment Co., Ltd. emphasizes: when your hydraulic pump (especially precision plunger pumps) requires extended storage, professional maintenance is mandatory to prevent irreversible damage. Below is our standardized 20-year field-validated maintenance procedure.

5 Technical Reasons for Complete Oil Drainage

1. Fluid Contamination: System "Blood" Purification

Hydraulic oil accumulates metal particles and dust during storage. Our lab data shows:

• 300% average increase in >5μm particles after 1-year storage

• These contaminants accelerate wear in precision components (valve plates, pistons)

2. Oil Degradation: Performance Deterioration

Oxidized hydraulic oil exhibits:

• Viscosity variation >±10%

• Increased acid number (>0.5mgKOH/g)

• Reduced demulsibility We recommend regular testing with oil analysis equipment or direct replacement.

3. Moisture Corrosion: Silent Killer

Stored pumps are prone to condensation causing:

• Plunger pump bushing corrosion

• Bearing pitting

• Valve spool sticking Our case studies show unmaintained pumps have 5x higher corrosion failure rates.

4. Seal Aging: Preventive Replacement

Key inspection points:

• Shaft seals (replace every 2 years)

• O-rings (replace every 3 years)

• Cover gaskets (replace every 5 years) OEM seals last 30% longer.

5. Performance Recovery: Renewed Efficiency

After oil change:

• Volumetric efficiency recovers to >95%

• Noise reduces by 3-5dB

• Temperature rise decreases 10-15℃

Professional 5-Step Hydraulic Pump Preservation

Step 1: Complete Oil Drainage

1. Operate pump for 3 minutes to reach 40-50℃

2. Open all drain ports (including case drain)

3. Blow residual oil with compressed air (≤0.3MPa)

Step 2: System Flushing

Use Guangdong Haozheng specialty flushing oil (ISO VG22):

• Plunger pumps: 30-minute flush

• Gear pumps: 15-minute flush Post-flush cleanliness: ISO 4406 18/16/13 standard

Step 3: Rust Prevention

1. Fill with preservative oil (e.g., Shell Ensis)

2. Manually rotate shaft 5-10 revolutions

3. Seal all ports

Step 4: Storage Environment Control

• Temperature: 15-35℃

• Humidity: ≤60%RH

• Recommended: Use desiccant cabinets

Step 5: Pre-commissioning Check

Before restart:

1. Install new filter (β≥200)

2. Fill with specified hydraulic oil

3. Run unloaded for 30 minutes

3 Expert Tips for Extended Service Life

1. Regular Wake-up: Unloaded operation every 3 months (10 minutes)

2. Oil Monitoring: Sample testing every 6 months

3. Professional Service: Contact Guangdong Haozheng for customized plans

For high-value plunger pumps, we recommend smart monitoring systems for real-time storage tracking. For technical support or OEM maintenance kits, please contact our service hotline.

(Technical standards established by Guangdong Haozheng Hydraulic Equipment Co., Ltd. R&D Center. Please credit source when reposting. Refer to equipment manuals for specific operations.)
